YSHIELD EMF Protection Paint (+ 5% VAT)

• Exceptional Shielding Performance: HSF54 offers up to 90 dB attenuation at 40 GHz, effectively blocking a wide range of frequencies, including those used in 5G networks.
• Versatile Application: Suitable for both interior and exterior surfaces, this paint adheres well to walls, ceilings, floors, and other substrates. Its high adhesive tensile strength ensures durability on various surfaces.
• Eco-Friendly Composition: Formulated without toxic solvents, plasticizers, or harmful chemicals, HSF54 is breathable, low-emission, and environmentally friendly.
• Certified Quality: TÜV-SÜD certification attests to the paint’s high shielding effectiveness and safety standards.

• Coverage: Approximately 4–8 square meters per liter, depending on surface texture and porosity.
• Color: Black (can be overpainted with standard emulsion paints for desired finish).
• Ingredients: Water, natural graphite, pure acrylic dispersion, carbon black, and additives.

1. Surface Preparation: Ensure the surface is clean, dry, and free from dust or grease. For absorbent substrates, apply a primer like YSHIELD® GK5 to enhance adhesion.
2. Mixing: Stir the paint thoroughly before use to achieve a uniform consistency.
3. Application: Use a paint roller or brush to apply an even coat. For optimal shielding, apply at least two coats, allowing each layer to dry completely before the next application.
4. Grounding: Since HSF54 is electrically conductive, it must be grounded to effectively shield against low-frequency electric fields. Consult a qualified electrician for proper grounding procedures.
5. Top Coating: Once the final coat is dry, the surface can be painted over with standard water-based emulsion paints to achieve the desired aesthetic finish.

YSHIELD's HSF54 is recognized by building biologists and EMF consultants for its effectiveness in reducing electromagnetic exposure. It is recommended in environments where minimizing EMFexposure is a priority, such as homes, offices, and healthcare facilities.

HSF54 is free from harmful chemicals, making it safe for indoor use. Its low-emission formula contributes to a healthier indoor environment, aligning with eco-conscious and health-focused values.

For a 5x5 meter room (25 square meters) with four walls and one ceiling:

1. Calculate the Total Surface Area:

• Eachwall: 5 meters (width) x 2.5 meters (average wall height) = 12.5 square meters per wall.
• Fourwalls: 12.5 square meters x 4 = 50 square meters.
• Ceiling: 5 meters x 5 meters = 25 square meters.
• Total Area: 50 square meters (walls) + 25 square meters (ceiling) = 75 square meters.

2. Determine Paint Quantity:

• TheHSF54paint typically covers 4–8 square meters per liter, depending on the surface’s porosity. For full EMF protection, apply two coats.
• First Coat: 75 square meters ÷ 4 (coverage per liter) = 18.75 liters.
• SecondCoat: Another 18.75 liters.

3. Total Paint Needed:

• 37.5liters for two coats over 75 square meters.
• Since HSF54 paint is sold in 5-liter containers, you’ll need approximately 8 containers for a 5x5 meter room with all walls and ceiling covered in two coats.
